SUPER POWER UPS 900 12V Pure Sign Wave (800VA), with M1603624TT 160AH/12V Inverter & Battery Combo
₹21,176₹29,890
Pure Sine Wave Output – Safe for sensitive appliances like TVs, computers, and audio systems.
Product Details
Technical Specifications
| Detail | Description |
|---|---|
| Inverter Warranty | 36 Months |
| Battery Warranty | 60 Months (36 Months Flat + 24 Months Pro-Rata) |
| Package Contents | 1 Inverter (UPS 900), 1 Tall Tubular Battery (150 Ah), Interconnecting Cable, Terminal Kit, User Manual, Warranty Card |
| Recommended Usage | Homes, offices, shops — powers lights, fans, LED TV, router, laptops, mixers, etc. |
| Installation Advice | Place battery in a cool, ventilated location. Ensure correct wiring and earthing. |
| Maintenance | For tubular battery: check & top up distilled water periodically, clean terminals, avoid deep discharge. |
| Safety Precautions | Do not overload inverter. Keep away from direct sunlight and moisture. Ensure good ventilation. |
| Category | Specification |
| Model | Super Power UPS 900 (12 V Pure Sine Wave) |
| VA Rating | 800 VA |
| Approx. Output Power | ~640 W |
| Input Voltage (Standard Range) | 100 V – 300 V AC |
| Input Voltage (Narrow Range) | 180 V – 260 V AC |
| Output Voltage on Mains | Same as input |
| Output Voltage on UPS Mode | 200 V – 230 V ±10% |
| Transfer Time | < 15 ms |
| Efficiency (Battery Mode) | > 80% |
| Charging Current | ~10 A (typical) |
| Protection | Overload, Short Circuit, Deep Discharge, Auto-Reset |
| Indicators | LED – Mains ON, UPS ON, Charging, Overload, Battery Low, Fault |
| Dimensions (Inverter) | ~34.4 × 39 × 20.7 cm (approx.) |
| Weight (Inverter) | ~7.7 kg |
| Model | M1603624TT Tall Tubular |
| Voltage | 12 V |
| Capacity | 160 Ah |
| Type | Tall Tubular, Deep Cycle |
| Warranty | 60 Months (36 Flat + 24 Pro-Rata) |
| Compatible Range | 80 Ah – 200 Ah batteries supported |
