SMART HYBRID NEW 875 (12V – 715VA/580W) Pure Sine Wave Inverter with M1603624TT 160Ah Battery Combo
₹20,918₹28,790
Smart Hybrid Technology (Digital + Sine Wave): Advanced Micro Controller design ensures pure sine wave output for silent, safe and efficient performance of appliances and sensitive electronics.
Product Details
Technical Specifications
| Particulars | Details |
|---|---|
| Brand | Microtek |
| Model Name | SMART HYBRID NEW 875 with M1603624TT |
| Inverter Type | Pure Sine Wave (Smart Hybrid – Digital + Sinewave) |
| Rated Capacity | 715VA / 580 Watts |
| Battery Type | Tall Tubular – M1603624TT (150Ah / 12V) |
| Battery Capacity | 160Ah (Single 12V Battery) |
| Battery Technology | Dura Core Technology for Long Life |
| Recommended Use | Home, Office, Shops, Small Business |
| Supported Battery System | 1 Battery (12V) |
| Input Voltage Range | 100V – 300V AC |
| Output Voltage | 230V ±10% (AC) |
| Output Frequency | 50Hz ±0.1Hz |
| Changeover / Switchover Time | < 15 milliseconds (UPS Mode) |
| Charging Current | 10A (Standard Mode) / 14A (Fast Charging Mode) |
| Waveform | Pure Sine Wave (Low Harmonic Distortion) |
| Display Indicators | LED Indicators for Mains, Charging, Battery, Overload, Fault |
| Protection Features | Overload, Short Circuit, Battery Deep Discharge, Overcharge Protection |
| Cooling System | Smart Auto Cooling Fan |
| Material Type | High-Grade Metal Cabinet with Ventilation |
| Warranty (Inverter) | 36 Months |
| Warranty (Battery) | 60 Months (36 Months Flat + 24 Months Pro-Rata) |
| Country of Origin | India |
| Manufacturer / Brand Owner | Microtek International Pvt. Ltd. |
| Customer Care | 1800-102-4447 / www.microtek.in |
| Specification | Inverter (SMART HYBRID NEW 875) |
| Rated Capacity | 715VA / 580W |
| Battery System | Single (12V) |
| Output Voltage | 230V ±10% AC |
| Waveform Type | Pure Sine Wave |
| Charging Current | 10A (Standard) / 14A (Fast) |
| Efficiency | >85% |
| Switchover Time | <15ms (UPS Mode) |
| Technology | Smart Hybrid (Digital + Sinewave) |
| Protection | Overload, Short Circuit, Battery Deep Discharge |
| Design Type | Wall / Floor Mountable Metal Cabinet |
| Dimensions (Approx.) | 35 x 38 x 19 cm |
| Weight (Approx.) | 9.5 kg |
| Warranty | 2 Years |
